FR-D740-050-NA Mitsubishi VFD
Description
The Mitsubishi Electric FR-D740-050-NA is a compact Variable Frequency Drive (VFD) from the FREQROL FR-D700 Series, offering dependable motor speed control for light industrial and commercial applications where simplicity and reliability are the priority.
Rated at 3HP (2.2kW) with a 5-amp output, this drive accepts three-phase input voltage from 380 to 480VAC, making it fully compatible with standard 400V, 415V, and 480V industrial power systems. The output frequency range of 0.2 to 400Hz supports a wide variety of motor control needs.
Built to US, Canadian, and Mexican specifications as indicated by the NA suffix, the FR-D740-050-NA carries an IP20 (UL Type 1) enclosure rating and is designed for panel or cabinet installation. Built-in Modbus RTU communication allows for straightforward integration with PLCs and automation controllers.
Standard features of the FR-D740-050-NA include PID control, multi-speed operation, slip compensation, optimum excitation control, speed smoothing control, automatic restart after power failure, and offline auto-tuning, providing users with a comprehensive feature set in a compact and affordable package.
Key Specifications:
- Input Voltage: 380–480VAC, 3-Phase
- Power Rating: 3HP / 2.2kW
- Output Current: 5A
- Output Frequency: 0.2–400Hz
- Communication: Modbus RTU
- Enclosure: IP20 / UL Type 1
- Series: Mitsubishi FREQROL FR-D700
More Information
| Part Number | FR-D740-050-NA |
|---|---|
| Manufacturer | Mitsubishi |
| Condition | Factory New |
| Country Of Origin | Japan |
| Warranty | 1 year warranty |
| Shipping Weight / Dimensions | Weight: 4.13LB
Dimensional Weight: 6.0LB
Dimensions: 8.7 x 7.6 x 8.15 |
| Type | Inverter Drives |
